HHI30-36-286TS Hyundai

HHI30-36-286TS Hyundai

Phase: 3
Hertz: 60 HZ
Enclosure: TEFC
HP: 30
Pole: 2
RPM: 3600
Frame: 286TS
Full Load Amps: 67.6 / 33.8 A USABLE ON 208 V AT 74.8 A
Weight: 410 lbs.
Nema Design: B
Duty: S1 / CONTINUOUS
Insulation Class: F CLASS N VARNISH
Ambient Teperature: 40° C AT 1.15 SF / 65° C AT 1.0 SF
Service Factor: 1.15 SF AT 40° C / 1.0 SF AT 65° C
Ingress Protection: IP55
Frame Material: CAST IRON

$ 2,155.34

Add to wishlist

Internal Reference: HHI30-36-286TS*
